LTD-6610E

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 2DIGIT ORN 0.56" CA
PDF
/
Buying Options
Total Price: USD $1.59
Unit Price: USD $1.592548
≥1 USD $1.592548
≥200 USD $0.635444
≥500 USD $0.614437
≥1000 USD $0.603934
Inventory: 2817
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Character Height 14.224mm
Viewing Area (height) 14.22mm
Height 8.128mm

Technical

Dominant Wavelength 621 nm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 2
Reverse Voltage 5V
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 630nm
Illumination Color Orange
Luminous Intensity 2.4 mcd
Current - Test 20mA
Forward Current 25mA
Power Dissipation 75mW
Element Configuration Common Anode
Number of Elements 16
Operating Supply Voltage 2V
Depth 19.05mm
Number of Functions 2
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Orange-Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.750 Hx0.984W x 0.315 D 19.05mmx25.00mmx8.00mm
Published 2000
Packaging Tube

Physical

Number of Pins 18
Package / Case 18-DIP (0.600, 15.24mm)
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
