LTD-5523AE

Lite-On Inc.
RoHS
/
Package 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 2DIGIT ORN 0.56" CC
PDF
/
Inventory: 9251
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Mount Through Hole
Package / Case 18-DIP (0.600, 15.24mm)
Number of Pins 18

Technical

Packaging Tube
Published 2000
Size / Dimension 0.673 Hx0.984W x 0.315 D 17.10mmx25.00mmx8.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Orange-Red
Additional Feature IC COMPATIBLE
Number of Functions 2
Depth 17.1mm
Operating Supply Voltage 2V
Number of Elements 16
Element Configuration Common Cathode
Power Dissipation 75mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 2.4 mcd
Illumination Color Orange
Wavelength - Peak 630nm
Power Consumption 75mW
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 2
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dominant Wavelength 621 nm

Dimensions

Height 17.0942mm
Viewing Area (height) 14.22mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
