LTD-5250G

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 2DIGIT GRN 0.52" CA
PDF
/
Inventory: 9822
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 13.2mm
Height 17.5514mm

Technical

Dominant Wavelength 569 nm
Common Pin Common Anode
Digit/Alpha Size 0.52 13.21mm
Number of Characters 2
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 565nm
Luminous Intensity 2.2 mcd
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 75mW
Element Configuration Common Anode
Number of Elements 16
Depth 17.55mm
Number of Functions 2
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Green
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 0.691 Hx0.988W x 0.276 D 17.55mmx25.10mmx7.00mm
Published 2000
Packaging Tube

Physical

Number of Pins 18
Package / Case 18-DIP (0.600, 15.24mm)
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
