LTD-5023AWC
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 2DIGIT RED LC 0.40" CC
PDF
/
Inventory: 965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 18-DIP (0.600, 15.24mm)
Technical
Packaging Tube
Published 2000
Size / Dimension 0.673 Hx0.984W x 0.315 D 17.10mmx25.00mmx8.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Color Red
Additional Feature IC COMPATIBLE
Number of Functions 2
Reach Compliance Code unknown
Operating Temperature (Max) 85°C
Operating Temperature (Min) -35°C
Power Dissipation-Max 75mW
Voltage - Forward (Vf) (Typ) 1.7V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 5mA
Luminous Intensity 3.75 mcd
Wavelength - Peak 660nm
Forward Current-Max 0.03A
Display Type 7-Segment
Number of Characters 2
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dimensions
Height 17.0942mm
Compliance
RoHS Status ROHS3 Compliant
