LTD-323JD

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 10-DIP (0.400, 10.16mm), 9 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 2DIGIT RED LC 0.30" CA
PDF
/
Inventory: 4382
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 7.62mm
Height 15.0114mm

Technical

Dominant Wavelength 639 nm
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 650nm
Millicandela Rating 0.6mcd
Luminous Intensity 600 μcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation-Max 70mW
Reach Compliance Code unknown
Number of Functions 2
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.591 Hx0.610W x 0.283 D 15.00mmx15.50mmx7.20mm
Published 2001
Packaging Tube

Physical

Package / Case 10-DIP (0.400, 10.16mm), 9 Leads

Supply Chain

Factory Lead Time 12 Weeks
