LTC-571P
RoHS
RoHS compliant
RoHS compliantPackage 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 3DIGIT RED 0.56" CC
PDF
/
Buying Options
Total Price: USD $2.64
Unit Price: USD $2.638929
≥1 USD $2.638929
≥195 USD $1.052946
≥494 USD $1.01881
≥1001 USD $1.00043
Inventory: 4757
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 12-DIP (0.600, 15.24mm)
Number of Pins 12
Technical
Packaging Tube
Size / Dimension 0.750 Hx1.484W x 0.315 D 19.05mmx37.70mmx8.00mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Red
Additional Feature IC COMPATIBLE
HTS Code 8541.40.20.00
Subcategory LED Displays
Number of Functions 3
Depth 19.05mm
Reach Compliance Code unknown
Number of Elements 24
Element Configuration Common Cathode
Power Dissipation 40mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 15mA
Current - Test 20mA
Luminous Intensity 950 μcd
Millicandela Rating 0.95mcd
Wavelength - Peak 697nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2.8V
Number of Characters 3
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dominant Wavelength 657 nm
Dimensions
Height 19.05mm
Viewing Area (height) 14.22mm
Compliance
RoHS Status ROHS3 Compliant
