LTC-4727Y
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.400, 10.16mm), 14 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 4DIGIT YLW 0.4" CC
PDF
/
Buying Options
Total Price: USD $2.84
Unit Price: USD $2.842429
≥1 USD $2.842429
≥204 USD $1.134346
≥504 USD $1.096272
≥996 USD $1.077891
Inventory: 2994
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 16-DIP (0.400, 10.16mm), 14 Leads
Number of Pins 14
Technical
Packaging Tube
Published 2010
Size / Dimension 0.504 Hx1.582W x 0.276 D 12.80mmx40.18mmx7.00mm
JESD-609 Code e0
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Yellow
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 4
Depth 12.8mm
Number of Elements 35
Element Configuration Common Cathode
Power Dissipation 60mW
Voltage - Forward (Vf) (Typ) 2.1V
Forward Current 20mA
Luminous Intensity 2.2 mcd
Millicandela Rating 2.2mcd
Wavelength - Peak 585nm
Display Type 7-Segment Clock
Reverse Voltage 5V
Forward Voltage-Max 2.6V
Number of Characters 4
Digit/Alpha Size 0.39 10.00mm
Common Pin Common Cathode
Dominant Wavelength 588 nm
Dimensions
Height 12.8016mm
Viewing Area (height) 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
