LTC-4727E
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.400, 10.16mm), 14 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 4DIGIT ORN 0.4" CC
PDF
/
Buying Options
Total Price: USD $2.84
Unit Price: USD $2.842429
≥1 USD $2.842429
≥204 USD $1.134346
≥504 USD $1.096272
≥996 USD $1.077891
Inventory: 1527
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10mm
Height 10.0076mm
Technical
Dominant Wavelength 621 nm
Common Pin Common Cathode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 4
Forward Voltage-Max 2.6V
Reverse Voltage 5V
Display Type 7-Segment Clock
Wavelength - Peak 630nm
Luminous Intensity 2.2 mcd
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 75mW
Element Configuration Common Cathode
Number of Elements 35
Depth 12.8mm
Number of Functions 4
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Orange-Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 0.394 Hx1.582W x 0.276 D 10.00mmx40.18mmx7.00mm
Published 2000
Packaging Tube
Physical
Number of Pins 14
Package / Case 16-DIP (0.400, 10.16mm), 14 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
