LTC-4724G
RoHS
RoHS compliant
RoHS compliantPackage 15-DIP (0.400, 10.16mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 3DIGIT GRN 0.4" CC
PDF
/
Buying Options
Total Price: USD $2.48
Unit Price: USD $2.475245
≥1 USD $2.475245
≥10 USD $2.335141
≥100 USD $2.202959
≥500 USD $2.078261
≥1000 USD $1.960629
Inventory: 1154
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10mm
Height 12.8016mm
Technical
Dominant Wavelength 569 nm
Common Pin Common Cathode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 3
Forward Voltage-Max 2.6V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 565nm
Luminous Intensity 2.2 mcd
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 75mW
Element Configuration Common Cathode
Number of Elements 27
Depth 12.8mm
Number of Functions 3
Subcategory LED Displays
HTS Code 8541.40.20.00
Additional Feature IC COMPATIBLE
Color Green
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 0.504 Hx1.182W x 0.276 D 12.80mmx30.02mmx7.00mm
Published 2010
Packaging Tube
Physical
Number of Pins 12
Package / Case 15-DIP (0.400, 10.16mm), 12 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
