LTC-4724E
RoHS
/
Package 15-DIP (0.400, 10.16mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 3DIGIT ORN 0.4" CC
PDF
/
Inventory: 7134
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Viewing Area (height) 10mm
Height 12.8016mm
Technical
Dominant Wavelength 621 nm
Common Pin Common Cathode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 3
Forward Voltage-Max 2.6V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 630nm
Luminous Intensity 2.2 mcd
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 75mW
Element Configuration Common Cathode
Number of Elements 27
Depth 12.8mm
Number of Functions 3
Subcategory LED Displays
HTS Code 8541.40.20.00
Additional Feature IC COMPATIBLE
Color Orange-Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Size / Dimension 0.504 Hx1.182W x 0.276 D 12.80mmx30.02mmx7.00mm
Published 2009
Packaging Tube
Physical
Number of Pins 12
Package / Case 15-DIP (0.400, 10.16mm), 12 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
