LTC-4624WC

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 15-DIP (0.400, 10.16mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 3DIGIT RED LC 0.4" CA
PDF
/
Inventory: 5639
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 10mm
Height 12.8016mm

Technical

Dominant Wavelength 638 nm
Common Pin Common Anode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 3
Forward Voltage-Max 2.4V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 660nm
Luminous Intensity 3.4 mcd
Current - Test 5mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation 75mW
Element Configuration Common Anode
Number of Elements 27
Reach Compliance Code unknown
Depth 12.8mm
Number of Functions 3
Subcategory LED Displays
HTS Code 8541.40.20.00
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e0
Size / Dimension 0.504 Hx1.182W x 0.276 D 12.80mmx30.02mmx7.00mm
Published 2000
Packaging Tube

Physical

Number of Pins 12
Package / Case 15-DIP (0.400, 10.16mm), 12 Leads
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
