LTC-4624P
RoHS
RoHS compliant
RoHS compliantPackage 15-DIP (0.400, 10.16mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 3DIGIT RED 0.4" CA
PDF
/
Buying Options
Total Price: USD $3.25
Unit Price: USD $3.248115
≥1 USD $3.248115
≥204 USD $1.295832
≥493 USD $1.252507
≥1003 USD $1.2315
Inventory: 1096
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 10mm
Height 12.8016mm
Technical
Dominant Wavelength 657 nm
Common Pin Common Anode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 3
Forward Voltage-Max 2.6V
Display Type 7-Segment
Power Consumption 40mW
Wavelength - Peak 697nm
Millicandela Rating 0.8mcd
Luminous Intensity 800 μcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Anode
Power Dissipation-Max 40mW
Operating Supply Voltage 2.1V
Number of Functions 3
Subcategory LED Displays
HTS Code 8541.40.20.00
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.504 Hx1.182W x 0.276 D 12.80mmx30.02mmx7.00mm
Published 2010
Packaging Tube
Physical
Package / Case 15-DIP (0.400, 10.16mm), 12 Leads
Supply Chain
Factory Lead Time 12 Weeks
