LTC-2723P
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm), 15 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 4DIGIT RED 0.28" CC
PDF
/
Inventory: 8744
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 16-DIP (0.300, 7.62mm), 15 Leads
Number of Pins 16
Technical
Packaging Tube
Published 2000
Size / Dimension 0.394 Hx1.191W x 0.240 D 10.00mmx30.26mmx6.10mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Red
Additional Feature IC COMPATIBLE
Number of Functions 4
Depth 10mm
Operating Supply Voltage 2.1V
Number of Elements 36
Power Dissipation-Max 40mW
Element Configuration Common Cathode
Power Dissipation 40W
Forward Current 20mA
Luminous Intensity 750 μcd
Millicandela Rating 0.75mcd
Wavelength - Peak 697nm
Power Consumption 40mW
Display Type 7-Segment Clock
Reverse Voltage 5V
Number of Characters 4
Digit/Alpha Size 0.28 7.00mm
Common Pin Common Cathode
Dominant Wavelength 657 nm
Dimensions
Height 10.0076mm
Viewing Area (height) 7mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Alternative Model
