LTC-2723JD

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 16-DIP (0.300, 7.62mm), 15 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 4DIGIT RED LC 0.28" CC
PDF
/
Buying Options
Total Price: USD $4.55
Unit Price: USD $4.550511
≥1 USD $4.550511
≥192 USD $1.815741
≥496 USD $1.755347
≥992 USD $1.725151
Inventory: 6217
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 7mm
Height 10.0076mm

Technical

Dominant Wavelength 640 nm
Common Pin Common Cathode
Digit/Alpha Size 0.28 7.00mm
Number of Characters 4
Reverse Voltage 5V
Display Type 7-Segment Clock
Wavelength - Peak 656nm
Millicandela Rating 0.6mcd
Luminous Intensity 600 μcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 70mW
Element Configuration Common Cathode
Number of Elements 35
Reach Compliance Code unknown
Depth 10mm
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.394 Hx1.191W x 0.240 D 10.00mmx30.26mmx6.10mm
Published 2001
Packaging Tube

Physical

Number of Pins 16
Package / Case 16-DIP (0.300, 7.62mm), 15 Leads
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
