LTC-2721P
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm), 13 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG .28" 3DIGIT BRT RED CC
PDF
/
Inventory: 9618
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 7mm
Height 6.096mm
Technical
Dominant Wavelength 657 nm
Common Pin Common Cathode
Digit/Alpha Size 0.28 7.00mm
Number of Characters 3
Reverse Voltage 5V
Display Type 7-Segment
Power Consumption 40mW
Wavelength - Peak 697nm
Millicandela Rating 0.75mcd
Luminous Intensity 750 μcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 40mW
Element Configuration Common Cathode
Number of Elements 27
Operating Supply Voltage 2.1V
Reach Compliance Code unknown
Depth 10mm
Number of Functions 3
HTS Code 8541.40.20.00
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.394 Hx0.891W x 0.240 D 10.00mmx22.64mmx6.10mm
Published 2000
Packaging Tube
Physical
Number of Pins 16
Package / Case 16-DIP (0.300, 7.62mm), 13 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
