LSHD-7803

Lite-On Inc.
RoHS
RoHS RoHS compliant
Package 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG .3" GREEN 565NM CC
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.408
≥1 USD $1.408
≥10 USD $0.8888
≥100 USD $0.657747
≥500 USD $0.604384
≥1000 USD $0.497728
≥3000 USD $0.472842
Inventory: 1087
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 7.62mm
Height 6.096mm

Technical

Dominant Wavelength 569 nm
Common Pin Common Cathode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 565nm
Millicandela Rating 1.6mcd
Luminous Intensity 1.6 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 75mW
Element Configuration Common Cathode
Number of Elements 8
Operating Supply Voltage 2.1V
Reach Compliance Code not_compliant
Depth 7.62mm
Number of Functions 1
Color Green
Min Operating Temperature -35°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
Published 2002
Packaging Tube

Physical

Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm)
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
