SC56-21GWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Green .56" 7-Segment 568 nm Common Cathode 25 mA LED Display
PDF
/
Buying Options
Total Price: USD $1.88
Unit Price: USD $1.8832
≥1 USD $1.8832
≥10 USD $1.25312
≥100 USD $0.96433
≥500 USD $0.871746
≥1000 USD $0.749144
≥3000 USD $0.708286
Inventory: 1170
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 14.2mm
Thickness 8mm
Height 19.05mm
Technical
Character Width 14.224mm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Power Consumption 62.5mW
Wavelength - Peak 565nm
Luminous Intensity 11 mcd
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.2V
Element Configuration Common Cathode
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.750 Hx0.500W x 0.315 D 19.05mmx12.70mmx8.00mm
Published 2011
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Supply Chain
Factory Lead Time 12 Weeks
