SC56-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 0.56" SGL 625NM RED
PDF
/
Buying Options
Total Price: USD $2.03
Unit Price: USD $2.0328
≥1 USD $2.0328
≥10 USD $1.3574
≥100 USD $1.04456
≥500 USD $0.944258
≥1000 USD $0.811474
≥3000 USD $0.76721
Inventory: 753
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Manufacturer Package Identifier SC56-11EWA
Technical
Packaging Tube
Published 2002
Size / Dimension 0.750 Hx0.500W x 0.315 D 19.05mmx12.70mmx8.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 1
Element Configuration Common Cathode
Power Dissipation 75mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 6.4 mcd
Millicandela Rating 6.4mcd
Wavelength - Peak 627nm
Power Consumption 75mW
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Character Width 14.224mm
Dimensions
Height 8.25mm
Character Height 14.2mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
