SC43-11YWA

Kingbright
RoHS
RoHS RoHS compliant
Package 14-DIP (0.300, 7.62mm), 11 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description KINGBRIGHT SC43-11YWA 7-Segment LED Display, Yellow, 20 mA, 2.1 V, 6.5 mcd, 1, 10.92 mm
PDF
/
Inventory: 6883
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Character Height 10.92mm
Height 18.9992mm

Technical

Common Pin Common Cathode
Digit/Alpha Size 0.43 10.92mm
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Wavelength - Peak 590nm
Millicandela Rating 6.5mcd
Luminous Intensity 6.5 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Yellow
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.748 Hx0.496W x 0.310 D 19.00mmx12.60mmx7.87mm
Published 2011
Packaging Tube

Physical

Package / Case 14-DIP (0.300, 7.62mm), 11 Leads

Supply Chain

Factory Lead Time 8 Weeks
