SC40-19EWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (4.210, 107.00mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
KINGBRIGHT SC40-19EWA 7-Segment LED Display, Red, 20 mA, 8 V, 44 mcd, 1, 101.2 mm
PDF
/
Inventory: 3299
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 101.2mm
Height 121.9962mm
Technical
Character Width 59.5mm
Background Color Grey
Common Pin Common Cathode
Digit/Alpha Size 3.98 101.20mm
Number of Segments 7
Number of Characters 1
Display Type 7-Segment
Power Consumption 600mW
Wavelength - Peak 627nm
Millicandela Rating 23mcd
Luminous Intensity 44 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 8V
Element Configuration Common Cathode
Row Spacing 107 mm
Lead Pitch 5.08mm
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 4.803 Hx3.543W x 0.591 D 122.00mmx90.00mmx15.00mm
Published 2002
Packaging Tube
Physical
Package / Case 10-DIP (4.210, 107.00mm)
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
