SC39-11CGKWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
KINGBRIGHT SC39-11CGKWA 7-Segment LED Display, Mechanically Rugged, Green, 20 mA, 2.1 V, 21 mcd, 1, 9.9 mm
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.64769
≥1 USD $1.64769
≥195 USD $0.657763
≥507 USD $0.635444
≥1014 USD $0.62494
Inventory: 1083
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 9.9mm
Height 13.0048mm
Technical
Character Width 6.2mm
Common Pin Common Cathode
Digit/Alpha Size 0.39 10.00mm
Number of Segments 7
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 574nm
Millicandela Rating 21mcd
Luminous Intensity 21 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.1V
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Number of Functions 1
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.512 Hx0.394W x 0.276 D 13.00mmx10.00mmx7.00mm
Published 2007
Packaging Tube
Physical
Package / Case 10-DIP (0.300, 7.62mm)
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
