SC36-11GWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Single Green 568nm Common Cathode
PDF
/
Buying Options
Total Price: USD $1.55
Unit Price: USD $1.5488
≥1 USD $1.5488
≥10 USD $1.03033
≥100 USD $0.792898
≥500 USD $0.716725
≥1000 USD $0.615938
≥3000 USD $0.58234
Inventory: 1130
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 9.14mm
Height 13.9954mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.36 9.14mm
Number of Characters 1
Display Type 7-Segment
Power Consumption 62.5mW
Wavelength - Peak 565nm
Millicandela Rating 3.5mcd
Luminous Intensity 3.5 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 62.5mW
Operating Supply Voltage 2.2V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
Published 2002
Packaging Tube
Physical
Package / Case 10-DIP (0.200, 5.08mm)
Supply Chain
Factory Lead Time 12 Weeks
