SC23-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (2.367, 60.10mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 627NM RED NUMERIC 2.3"
PDF
/
Inventory: 2037
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Character Height 56.9mm
Height 70.0024mm
Technical
Character Width 32.2mm
Common Pin Common Cathode
Digit/Alpha Size 2.24 56.90mm
Number of Segments 7
Number of Characters 1
Display Type 7-Segment
Power Consumption 300mW
Wavelength - Peak 627nm
Millicandela Rating 57mcd
Luminous Intensity 57 mcd
Forward Current 20mA
Element Configuration Common Cathode
Power Dissipation-Max 300mW
Operating Supply Voltage 8V
Number of Functions 1
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 2.756 Hx1.890W x 0.472 D 70.00mmx48.00mmx12.00mm
Published 2002
Packaging Tube
Physical
Package / Case 10-DIP (2.367, 60.10mm)
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
