SC10-11GWA
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.600, 15.24mm), 11 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Kingbright SC10-11GWA 1" Green LED Display Cathode
PDF
/
Inventory: 1752
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 14-DIP (0.600, 15.24mm), 11 Leads
Technical
Packaging Tube
Published 2011
Size / Dimension 1.295 Hx0.886W x 0.335 D 32.90mmx22.50mmx8.50mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 1
Operating Supply Voltage 4.4V
Power Dissipation-Max 125mW
Element Configuration Common Cathode
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 37 mcd
Millicandela Rating 37mcd
Wavelength - Peak 565nm
Power Consumption 125mW
Display Type 7-Segment
Forward Voltage-Max 2.5V
Number of Characters 1
Digit/Alpha Size 1.02 26.00mm
Common Pin Common Cathode
Dimensions
Height 32.893mm
Compliance
RoHS Status ROHS3 Compliant
