SC08-11SURKWA
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.600, 15.24mm), 13 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
KINGBRIGHT SC08-11SURKWA 7-Segment LED Display, Mechanically Rugged, Red, 20 mA, 1.95 V, 61 mcd, 1, 20.32 mm
PDF
/
Buying Options
Total Price: USD $2.66
Unit Price: USD $2.6576
≥1 USD $2.6576
≥10 USD $1.881246
≥100 USD $1.540977
≥500 USD $1.299065
≥1000 USD $1.191564
≥3000 USD $1.142284
Inventory: 1090
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 16-DIP (0.600, 15.24mm), 13 Leads
Technical
Packaging Tube
Published 2007
Size / Dimension 1.091 Hx0.787W x 0.331 D 27.70mmx20.00mmx8.40mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Number of Functions 1
Power Dissipation-Max 75mW
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 1.95V
Forward Current 20mA
Luminous Intensity 61 mcd
Millicandela Rating 61mcd
Wavelength - Peak 645nm
Display Type 7-Segment
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.80 20.32mm
Common Pin Common Cathode
Dominant Wavelength 630 nm
Character Width 11mm
Dimensions
Height 27.7114mm
Viewing Area (height) 20.32mm
Character Height 20.32mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
