SC08-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Single Red 625nm Common Cathode
PDF
/
Buying Options
Total Price: USD $2.66
Unit Price: USD $2.6576
≥1 USD $2.6576
≥10 USD $1.881246
≥100 USD $1.540977
≥500 USD $1.299065
≥1000 USD $1.191564
≥3000 USD $1.142284
Inventory: 681
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 20.32mm
Height 27.7114mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 627nm
Luminous Intensity 8 mcd
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Element Configuration Common Cathode
Operating Supply Voltage 2.5V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 1.091 Hx0.787W x 0.331 D 27.70mmx20.00mmx8.40mm
Published 2002
Packaging Tube
Physical
Package / Case 18-DIP (0.600, 15.24mm)
Supply Chain
Factory Lead Time 8 Weeks
