SC04-12SURKWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.295, 7.50mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories .4 SINGLE DIGIT RED LED DISPLAY
PDF
/
Inventory: 1873
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Character Height 10.16mm
Height 18.7452mm
Technical
Character Width 5.58mm
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Segments 7
Number of Characters 1
Display Type 7-Segment
Forward Current-Max 0.03A
Wavelength - Peak 645nm
Luminous Intensity 80 mcd
Current - Test 20mA
Voltage - Forward (Vf) (Typ) 1.95V
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Number of Functions 1
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.738 Hx0.386W x 0.200 D 18.75mmx9.80mmx5.08mm
Published 2013
Packaging Tube
Physical
Package / Case 10-DIP (0.295, 7.50mm)
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
