SC04-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.295, 7.50mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 0.4" SGL 625NM RED
PDF
/
Buying Options
Total Price: USD $2.85
Unit Price: USD $2.85
≥1 USD $2.85
≥10 USD $1.46495
≥100 USD $1.38203
≥500 USD $1.3038
≥1000 USD $1.23
≥3000 USD $1.16038
Inventory: 1000
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 14-DIP (0.295, 7.50mm)
Technical
Packaging Tube
Published 2002
Size / Dimension 0.738 Hx0.386W x 0.200 D 18.75mmx9.80mmx5.08mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 1
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 5.6 mcd
Millicandela Rating 5.6mcd
Wavelength - Peak 627nm
Power Consumption 75mW
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.40 10.16mm
Common Pin Common Cathode
Dimensions
Height 18.7452mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
