SC03-12SURKWA

Kingbright
RoHS
RoHS RoHS compliant
Package 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 630NM RED 1DIG 0.3 TH
PDF
/
Inventory: 2957
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Through Hole
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads

Technical

Packaging Tube
Published 2014
Size / Dimension 0.750 Hx0.400W x 0.240 D 19.06mmx10.16mmx6.10mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Number of Functions 1
Power Dissipation-Max 75mW
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 1.95V
Current - Test 20mA
Luminous Intensity 67 mcd
Wavelength - Peak 645nm
Forward Current-Max 0.03A
Display Type 7-Segment
Forward Voltage-Max 2.5V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Cathode
Character Width 5.11mm

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Character Height 7.62mm
Height 19.05mm
