SC03-12EWA
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 0.3" SGL 625NM RED
PDF
/
Buying Options
Total Price: USD $2.06
Unit Price: USD $2.0592
≥1 USD $2.0592
≥10 USD $1.373812
≥100 USD $1.057188
≥500 USD $0.955645
≥1000 USD $0.821251
≥3000 USD $0.776459
Inventory: 633
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 7.62mm
Height 19.05mm
Technical
Character Width 7.62mm
Common Pin Common Cathode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 627nm
Millicandela Rating 8.1mcd
Luminous Intensity 8.5 mcd
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Operating Supply Voltage 2V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.750 Hx0.400W x 0.240 D 19.06mmx10.16mmx6.10mm
Published 2011
Packaging Tube
Physical
Package / Case 14-DIP (0.300, 7.62mm)
Supply Chain
Factory Lead Time 12 Weeks
