SA56-21YWA

Kingbright
RoHS
RoHS RoHS compliant
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories YELLOW DIFFUSED 1 DIGIT
PDF
/
Buying Options
Total Price: USD $1.71
Unit Price: USD $1.713335
≥1 USD $1.713335
≥200 USD $0.684021
≥480 USD $0.661702
≥1000 USD $0.649886
Inventory: 1162
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Character Height 14.2mm
Height 19.05mm

Technical

Character Width 14.224mm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Wavelength - Peak 590nm
Luminous Intensity 6.5 mcd
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Anode
Power Dissipation-Max 75mW
Operating Supply Voltage 2.1V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.750 Hx0.500W x 0.315 D 19.05mmx12.70mmx8.00mm
Published 2011
Packaging Tube

Physical

Package / Case 10-DIP (0.600, 15.24mm)

Supply Chain

Factory Lead Time 12 Weeks
