SA56-21SRWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories .56 RED COMMON ANODE
PDF
/
Inventory: 4903
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10
Technical
Packaging Tube
Published 2002
Size / Dimension 0.750 Hx0.500W x 0.315 D 19.05mmx12.70mmx8.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 1
Operating Supply Voltage 1.85V
Power Dissipation-Max 75mW
Element Configuration Common Anode
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 30mA
Current - Test 20mA
Luminous Intensity 34 mcd
Wavelength - Peak 660nm
Display Type 7-Segment
Forward Voltage-Max 2.5V
Number of Characters 1
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Anode
Character Width 14.224mm
Dimensions
Height 19.05mm
Character Height 14.2mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
