SA43-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Single Red 625nm Common Anode
PDF
/
Buying Options
Total Price: USD $1.83
Unit Price: USD $1.8304
≥1 USD $1.8304
≥10 USD $1.218466
≥100 USD $0.937622
≥500 USD $0.847554
≥1000 USD $0.728367
≥3000 USD $0.688644
Inventory: 1224
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 10.92mm
Height 18.9992mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.43 10.92mm
Number of Characters 1
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 627nm
Millicandela Rating 6.9mcd
Luminous Intensity 12 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Element Configuration Common Anode
Operating Supply Voltage 2.5V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.748 Hx0.496W x 0.310 D 19.00mmx12.60mmx7.87mm
Published 2002
Packaging Tube
Physical
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Supply Chain
Factory Lead Time 12 Weeks
