SA40-18SYKWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (4.210, 107.00mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
7-Segment 1 Yellow Common Anode LED Character Numeric Display Module 4V 20mA 150mW 450mcd
PDF
/
Buying Options
Total Price: USD $25.49
Unit Price: USD $25.490075
≥1 USD $25.490075
≥10 USD $24.047234
≥100 USD $22.686075
≥500 USD $21.401956
≥1000 USD $20.190529
Inventory: 2598
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Character Height 101.2mm
Height 121.9962mm
Technical
Character Width 59.5mm
Common Pin Common Anode
Digit/Alpha Size 3.98 101.20mm
Number of Segments 7
Number of Characters 1
Display Type 7-Segment
Forward Current-Max 0.06A
Wavelength - Peak 590nm
Luminous Intensity 450 mcd
Current - Test 20mA
Voltage - Forward (Vf) (Typ) 4V
Element Configuration Common Anode
Power Dissipation-Max 150mW
Number of Functions 1
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 4.803 Hx3.543W x 0.591 D 122.00mmx90.00mmx15.00mm
Published 2013
Packaging Tube
Physical
Package / Case 10-DIP (4.210, 107.00mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
