SA40-18EWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (4.210, 107.00mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories HI EFF RED DIFFUSED 1 DIGIT
PDF
/
Inventory: 4259
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 121.9962mm
Technical
Character Width 101.6mm
Common Pin Common Anode
Digit/Alpha Size 3.98 101.20mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 627nm
Luminous Intensity 2.3 mcd
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 8V
Element Configuration Common Anode
Power Dissipation-Max 600mW
Operating Supply Voltage 2V
Number of Functions 1
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 4.803 Hx3.543W x 0.591 D 122.00mmx90.00mmx15.00mm
Published 2011
Packaging Tube
Physical
Package / Case 10-DIP (4.210, 107.00mm)
Supply Chain
Factory Lead Time 8 Weeks
