SA36-11SRWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories SUPER RED DIFFUSED 1 DIGIT
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 425
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 13.9954mm
Technical
Character Width 9.144mm
Common Pin Common Anode
Digit/Alpha Size 0.36 9.14mm
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Wavelength - Peak 660nm
Luminous Intensity 10 mcd
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Anode
Power Dissipation-Max 75mW
Operating Supply Voltage 1.85V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
Published 2002
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm)
Supply Chain
Factory Lead Time 12 Weeks
