SA10-21SRWA

Kingbright
RoHS
RoHS RoHS compliant
Package 10-DIP (1.200, 30.48mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories 7 LED DISPLAY
PDF
/
Buying Options
Total Price: USD $10.87
Unit Price: USD $10.869499
≥1 USD $10.869499
≥200 USD $4.337822
≥500 USD $4.19209
≥1000 USD $4.121193
Inventory: 1114
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Character Height 25.4mm
Height 34.0106mm

Technical

Character Width 25.4mm
Common Pin Common Anode
Digit/Alpha Size 1.00 25.40mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Wavelength - Peak 660nm
Millicandela Rating 120mcd
Luminous Intensity 101 mcd
Current - Test 20mA
Forward Current 30mA
Voltage - Forward (Vf) (Typ) 3.7V
Element Configuration Common Anode
Power Dissipation-Max 150mW
Operating Supply Voltage 1.85V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 1.339 Hx0.945W x 0.413 D 34.00mmx24.00mmx10.50mm
Published 2002
Packaging Tube

Physical

Number of Pins 10
Package / Case 10-DIP (1.200, 30.48mm)
Mount Through Hole

Supply Chain

Factory Lead Time 12 Weeks
