SA08-21SRWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm), 15 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Single Red 640nm Common Anode
PDF
/
Buying Options
Total Price: USD $4.02
Unit Price: USD $4.016161
≥1 USD $4.016161
≥200 USD $1.603051
≥500 USD $1.549222
≥1000 USD $1.522964
Inventory: 1274
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 24.9936mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 660nm
Millicandela Rating 36mcd
Luminous Intensity 36 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.85V
Element Configuration Common Anode
Number of Functions 1
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.984 Hx0.732W x 0.417 D 25.00mmx18.60mmx10.60mm
Published 2007
Packaging Tube
Physical
Package / Case 18-DIP (0.600, 15.24mm), 15 Leads
Supply Chain
Factory Lead Time 12 Weeks
