SA05-11YWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Single Yellow 588nm Common Anode
PDF
/
Inventory: 6005
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 12.7mm
Height 18.9992mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.50 12.70mm
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Wavelength - Peak 590nm
Millicandela Rating 6.1mcd
Luminous Intensity 6.1 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.1V
Element Configuration Common Anode
Power Dissipation-Max 75mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Yellow
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.748 Hx0.500W x 0.315 D 19.00mmx12.70mmx8.00mm
Published 2011
Packaging Tube
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Supply Chain
Factory Lead Time 8 Weeks
