SA05-11SRWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Single Red 640nm Common Anode
PDF
/
Inventory: 8514
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10
Technical
Packaging Tube
Published 2011
Size / Dimension 0.748 Hx0.500W x 0.315 D 19.00mmx12.70mmx8.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 1
Operating Supply Voltage 1.85V
Power Dissipation-Max 75mW
Element Configuration Common Anode
Forward Current 20mA
Luminous Intensity 34 mcd
Millicandela Rating 34mcd
Wavelength - Peak 660nm
Power Consumption 75mW
Display Type 7-Segment
Forward Voltage-Max 2.5V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.50 12.70mm
Common Pin Common Anode
Character Width 7.3mm
Dimensions
Height 18.9992mm
Character Height 12.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
