SA05-11GWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Single Green 568nm Common Anode
PDF
/
Buying Options
Total Price: USD $1.7
Unit Price: USD $1.6984
≥1 USD $1.6984
≥10 USD $1.13256
Inventory: 118
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 12.7mm
Height 18.9992mm
Technical
Character Width 7.3mm
Common Pin Common Anode
Digit/Alpha Size 0.50 12.70mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Power Consumption 62.5mW
Wavelength - Peak 565nm
Millicandela Rating 10mcd
Luminous Intensity 10 mcd
Forward Current 20mA
Element Configuration Common Anode
Power Dissipation-Max 62.5mW
Operating Supply Voltage 2.2V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.748 Hx0.500W x 0.315 D 19.00mmx12.70mmx8.00mm
Published 2001
Packaging Tube
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 8 Weeks
