SA05-11CGKWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
KINGBRIGHT SA05-11CGKWA 7-Segment LED Display, Green, 30 mA, 2.1 V, 34000 cd, 1, 12.7 mm
PDF
/
Buying Options
Total Price: USD $1.91
Unit Price: USD $1.905018
≥1 USD $1.905018
≥200 USD $0.760169
≥480 USD $0.735224
≥1000 USD $0.723408
Inventory: 1142
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 12.7mm
Height 18.9992mm
Technical
Character Width 7.3mm
Common Pin Common Anode
Digit/Alpha Size 0.50 12.70mm
Number of Segments 7
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 574nm
Luminous Intensity 34 mcd
Current - Test 20mA
Forward Current 30mA
Voltage - Forward (Vf) (Typ) 2.1V
Element Configuration Common Anode
Power Dissipation-Max 75mW
Number of Functions 1
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.748 Hx0.500W x 0.315 D 19.00mmx12.70mmx8.00mm
Published 2010
Packaging Tube
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
