SA04-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.295, 7.50mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 0.4" SGL 625NM RED
PDF
/
Buying Options
Total Price: USD $1.98
Unit Price: USD $1.98
≥1 USD $1.98
≥10 USD $1.322605
≥100 USD $1.01787
≥500 USD $0.920093
≥1000 USD $0.790698
≥3000 USD $0.747569
Inventory: 438
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 18.7452mm
Technical
Character Width 10.16mm
Common Pin Common Anode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 627nm
Luminous Intensity 5.6 mcd
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Anode
Power Dissipation-Max 75mW
Operating Supply Voltage 2V
Number of Functions 1
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.738 Hx0.386W x 0.200 D 18.75mmx9.80mmx5.08mm
Published 2002
Packaging Tube
Physical
Package / Case 14-DIP (0.295, 7.50mm)
Supply Chain
Factory Lead Time 12 Weeks
