PSA05-12EWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.500, 12.70mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories AlphaNum Red 625nm Common Anode
PDF
/
Inventory: 4171
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 24.9936mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.50 12.70mm
Number of Characters 1
Display Type 16-Segment, Alphanumeric
Power Consumption 75mW
Wavelength - Peak 627nm
Millicandela Rating 7.6mcd
Luminous Intensity 7.6 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2V
Element Configuration Common Anode
Number of Functions 1
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.984 Hx0.630W x 0.374 D 25.00mmx16.00mmx9.50mm
Published 2011
Packaging Tube
Physical
Package / Case 18-DIP (0.500, 12.70mm)
Supply Chain
Factory Lead Time 8 Weeks
