PSA05-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.500, 12.70mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories AlphaNum Red 625nm Common Anode
PDF
/
Inventory: 8175
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 18-DIP (0.500, 12.70mm)
Technical
Packaging Tube
Published 2002
Size / Dimension 0.984 Hx0.630W x 0.374 D 25.00mmx16.00mmx9.50mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature IC COMPATIBLE
Number of Functions 1
Element Configuration Common Anode
Voltage - Forward (Vf) (Typ) 2V
Forward Current 20mA
Luminous Intensity 7.6 mcd
Millicandela Rating 7.6mcd
Wavelength - Peak 627nm
Power Consumption 75mW
Display Type 16-Segment, Alphanumeric
Number of Characters 1
Digit/Alpha Size 0.50 12.70mm
Common Pin Common Anode
Dimensions
Height 24.9936mm
Compliance
RoHS Status ROHS3 Compliant
