DC56-11GWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories GRN COMMON CATHODE
PDF
/
Buying Options
Total Price: USD $2.93
Unit Price: USD $2.9304
≥1 USD $2.9304
≥10 USD $2.06976
≥100 USD $1.695408
≥500 USD $1.429243
≥1000 USD $1.310954
≥3000 USD $1.256746
Inventory: 791
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Package / Case 18-DIP (0.600, 15.24mm)
Number of Pins 18
Technical
Packaging Tube
Published 2002
Size / Dimension 0.750 Hx0.984W x 0.315 D 19.05mmx25.00mmx8.00mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green
Additional Feature IC COMPATIBLE
Subcategory LED Displays
Number of Functions 2
Operating Supply Voltage 2.2V
Power Dissipation-Max 62.5mW
Element Configuration Common Cathode
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 11 mcd
Millicandela Rating 11mcd
Wavelength - Peak 565nm
Display Type 7-Segment
Number of Characters 2
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Character Width 14.224mm
Dimensions
Height 19.05mm
Character Height 14.22mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
