DC56-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories RED COMMON CATHODE 2 DIGIT
PDF
/
Buying Options
Total Price: USD $2.93
Unit Price: USD $2.9304
≥1 USD $2.9304
≥10 USD $2.06976
≥100 USD $1.695408
≥500 USD $1.429243
≥1000 USD $1.310954
≥3000 USD $1.256746
Inventory: 1185
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 14.22mm
Height 19.05mm
Technical
Character Width 14.224mm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 627nm
Millicandela Rating 8mcd
Luminous Intensity 2.4 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Operating Supply Voltage 2V
Number of Functions 2
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.750 Hx0.984W x 0.315 D 19.05mmx25.00mmx8.00mm
Published 2002
Packaging Tube
Physical
Number of Pins 18
Package / Case 18-DIP (0.600, 15.24mm)
Supply Chain
Factory Lead Time 12 Weeks
