DC04-11EWA

Kingbright
RoHS
RoHS RoHS compliant
Package 16-DIP (0.500, 12.70mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories HI EFF RED DIFFUSED 2 DIGIT
PDF
/
Buying Options
Total Price: USD $2.99
Unit Price: USD $2.990786
≥1 USD $2.990786
≥200 USD $1.193426
≥500 USD $1.154039
≥1000 USD $1.134346
Inventory: 6437
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Character Height 10mm
Height 16.002mm

Technical

Character Width 10.16mm
Common Pin Common Cathode
Digit/Alpha Size 0.39 10.00mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 627nm
Luminous Intensity 6.4 mcd
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Operating Supply Voltage 2V
Number of Functions 2
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.630 Hx0.795W x 0.276 D 16.00mmx20.20mmx7.00mm
Published 2002
Packaging Tube

Physical

Number of Pins 16
Package / Case 16-DIP (0.500, 12.70mm)

Supply Chain

Factory Lead Time 8 Weeks
