DC03-11EWA
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.400, 10.16mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Dual Red 625nm Common Cathode
PDF
/
Buying Options
Total Price: USD $4.28
Unit Price: USD $4.28268
≥1 USD $4.28268
≥192 USD $1.709396
≥512 USD $1.651628
≥992 USD $1.624057
Inventory: 1293
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 7.62mm
Height 15.0114mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 2
Display Type 7-Segment
Power Consumption 75mW
Wavelength - Peak 627nm
Millicandela Rating 3.1mcd
Luminous Intensity 3.1 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Element Configuration Common Cathode
Power Dissipation-Max 75mW
Operating Supply Voltage 2V
Number of Functions 2
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.591 Hx0.610W x 0.283 D 15.00mmx15.50mmx7.20mm
Published 2002
Packaging Tube
Physical
Package / Case 10-DIP (0.400, 10.16mm)
Supply Chain
Factory Lead Time 12 Weeks
