DA56-11EWA

Kingbright
RoHS
RoHS RoHS compliant
Package 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 627NM HRED 2DIG 0.56" TH
PDF
/
Buying Options
Total Price: USD $3.43
Unit Price: USD $3.432049
≥1 USD $3.432049
≥10 USD $3.237782
≥100 USD $3.054517
≥500 USD $2.881614
≥1000 USD $2.718507
Inventory: 1149
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Character Height 14.22mm

Technical

Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 2
Display Type 7-Segment
Wavelength - Peak 627nm
Millicandela Rating 8mcd
Luminous Intensity 8 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 75mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 2
Subcategory LED Displays
Additional Feature IC COMPATIBLE
Color Red
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Size / Dimension 0.750 Hx0.984W x 0.315 D 19.05mmx25.00mmx8.00mm
Published 2002
Packaging Tube

Physical

Package / Case 18-DIP (0.600, 15.24mm)

Supply Chain

Factory Lead Time 8 Weeks
